BT30ER16100 - BT30 ER16-100 Collet Chuck

JIS B 6339 (MAS403 BT) AD&B Balanced G6.3

BT30 ER16 100 Collet Chuck

• Collet Type and Ø Clamping Rance: ER16 100 Ø1-12.5mm
• Coolant Type: AD&B
• Balance: G6.3
• D: 28mm
• L: 100mm
• Locknut Type and Code: ER16 Altıköşe - NER16H
• Spanner Type and Code: SPER16 Altıköşe - SPER16H (Sold Separately)
• Pull Stud: M12 (Sold Separately)
• Adjustable Stop Screw Inside The Chuck
• Pack of: 1 Pce
• G2.5 Balanced Available on Request
• Brand: Gürkan
